Packaging machine 9 mm
| Standard | Dynamic | |
|---|---|---|
| Type of machine | DB 900 150 | DB 900 300 |
| Final product | complete box with 50pcs cartridge | complete box with 50pcs cartridge |
| Input components | cartridge, paper box, plastic organizer | cartridge, paper box, plastic organizer |
| Concept | linear machine with manipulator | linear machine with 6axis robot |
| Capacity | 150pcs/min 3boxs/min 50pcs/min in box | 300pcs/min 6boxs/min 50pcs in box |
| Power/Voltage | 3,2kW/3x400V | 5kW/3x400V |
| Process control | remote control PLC + Micro Tik support service | remote control PLC + Micro Tik support service |
| Air pressure | 6 bar | 6 bar |
| Dimensions | length 2,8 m x height 2,5 m x width 1,8 m | length 3,8 m x height 2,5 m x width 2,1 m |
| Weight of the machine | 2,6 t | 3 t |
| Feeder | one feeder | two feeders |
| Product | filled paper box | filled paper box |
| Special function | date printing on the box | date printing on the box |
| Filling conveyor | option | option |
| Machine output of product | slope conveyor | slope conveyor |
Technology is used for automatic packaging of cartridges in customer´s packaging according to sales standard – 50pcs of cartridges in plastic organizer and paper box.
It is possible to pack cartridges in bulk packaging, if it is required.
Packaging of boxes with 50pcs of cartridge can be further automated – robotization in bigger transport packaging (cardboard box).
Automatic station can be a part of assembly line for ammo production and service is provided by one operator.
The device can be produced for caliber 9x18mm, 9x19mm.
Packaging machine 5,56 mm
| Standard | Dynamic | |
|---|---|---|
| Type of machine | DB 556 125 | DB 556 250 |
| Final product | complete box with 20pcs cartridge | complete box with 20pcs cartridge |
| Input components | cartridge, paper box | cartridge, paper box |
| Concept | linear machine with manipulator | linear machine with manipulator |
| Capacity | 125pcs/min 6,25boxes/min 20pcs in box | 250pcs/min 12,5boxes/min 20pcs in box |
| Power/Voltage | 3,2kW/3x400V | 5kW/3x400V |
| Process control | remote control PLC + Micro Tik support service | remote control PLC + Micro Tik support service |
| Air pressure | 6 bar | 6 bar |
| Dimensions | length 4 m x height 2,8 m x width 1,8 m | length 5,5 m x height 2,8 m x width 2,5 m |
| Weight of the machine | 2,6 t | 3 t |
| Feeder | two feeders | four feeders |
| Product | filled paper box | filled paper box |
| Special function | date printing on the box | date printing on the box |
| Filling conveyor | option | option |
| Machine output of product | slope conveyor | slope conveyor |
Technology is used for automatic packaging of cartridges in customer´s packaging according to sales standard – 20pcs ofcartridges in paper box.
It is possible to pack cartridges in bulk packaging, if it is required.
Packaging of boxes with 20pcs of cartridge can be further automated – robotization in bigger transport packaging (cardboard box).
Automatic station can be a part of assembly line for ammo production and service is provided by one operator.
As option can be done implementation of camera check and sealing of primer and bullet – for NATO standard.
The device can be produced for caliber 5,56x45mm and .223REM.
Packaging machine 7,62 mm
| Standard | Dynamic | |
|---|---|---|
| Type of machine | DB 762 125 | DB 762 250 |
| Final product | complete box with 20pcs cartridge | complete box with 20pcs cartridge |
| Input components | cartridge, paper box | cartridge, paper box |
| Concept | linear machine with manipulator | linear machine with manipulator |
| Capacity | 125pcs/min 6.25boxes/min 20pcs in box | 250pcs/min 12,5boxes/min 20pcs in box |
| Power/Voltage | 3,2kW/3x400V | 5kW/3x400V |
| Process control | remote control PLC + Micro Tik support service | remote control PLC + Micro Tik support service |
| Air pressure | 6 bar | 6 bar |
| Dimensions | length 4 m x height 2,8 m x width 1,8 m | length 5,5 m x height 2,8 m x width 2,5 m |
| Weight of the machine | 2,6 t | 3 t |
| Feeder | two feeders | four feeders |
| Product | filled paper box | filled paper box |
| Special function | date printing on the box | date printing on the box |
| Filling conveyor | option | option |
| Machine output of product | slope conveyor | slope conveyor |
Technology is used for automatic packaging of cartridges in customer´s packaging according to sales standard – 20pcs of cartridges in paper box.
It is possible to pack cartridges in bulk packaging, if it is required.
Packaging of boxes with 20pcs of cartridge can be further automated – robotization in bigger transport packaging (cardboard box).
Automatic station can be a part of assembly line for ammo production and service is provided by one operator.
As option can be done implementation of camera check and sealing of primer and bullet – for NATO standard.
The device can be produced for caliber 7,62x39mm and 7,62x51mm.
